Companies Specialization BM-Engineering
- raw materials and working capital for the production analysis
- the basic equipment calculation
- the additional equipment and machinery calculation
- the installation, commissioning, personnel training cost
- the manufacturing area preparation cost calculation
- the production or return material repair cost value calculation
- the profitability or return material repair cost calculation
- recoupment of capital investment calculation The calculation cost is determined after official request and receipt the list and completeness of our services forming
- EQUIPMENT PRODUCTION: pellets/ briquette manufacturing lines, drying complexes, desintegrators, presses for biomass
- INDUSTRIAL COMPLEXES INSTALLATION: design, manufacturing areas search, construction, commissioning
- STARTING-UP AND ADJUSTMENT OF EQUIPMENT: Equipment launch and adjustment
- PERSONNEL TEACHING: engineering department work organization, sales, logistics, marketing departments creation from beginning
- SERVICE: full service and backup service
- MANUFACTURING AUTOMATION: monitoring and accounting systems introduction in the manufacturing
- CERTIFYING: preparing to certifying by EN+, ISO
Company BM Engineering Specialization:
Revolution in the biopolymers processing field
Company «BM-Engineering» Specialization
New areas in biopolimers processing
Gas-producing boiler КGGP Series
Specialized seminar “Pellet’s production industrial engineer”
Services for the Green Economy
Engineering company BM Engineering in the field of biomass processing for the first time in Ukraine market provides a full range of services in creating a turnkey modern plant for biomass refining, which produce pellets, briquettes and feed. In the preparation project stage the company experts give a qualified opinion on the feasibility of the facility construction, its perceived profitability and payback period.
We analyze future production from A to Z! We begin a study from the amount of the raw material base, its quality, supply logistics calculating. The biomass amount at an early stage and supplies it should be sufficient for the smooth operation of the equipment for a long time. Based on objective information collected about the future manufacturing, we calculate the main equipment characteristics, and optional additional equipment and tools parameters.
The total cost of the project must include the costs of the manufacturing area preparing, installation and commissioning, personnel training. And in the forecast we takes into account the cost of production advance energy efficiency and specific cost per unit of finished products production, its technical and quality characteristics, compliance with international standards, profitability and payback period of the investment. The production of extruded feed equipment using significantly increases the profitability of livestock farming by improving feed quality and reducing costs.
Certification and auditing of the pellets production in accordance with the European standards series EN 17461 provides that at all stages from the biological raw materials preparation and quality control to pellet’s manufacture, their packaging, labeling, storage, delivery and use, you must strictly comply with single standards, specifications and rules. In accordance with the ENplus system the certificate is necessary to obtain on a specific bio-fuel batch after appropriate tests in all parameters in a certified laboratory. Remember! Certified products worth several times more expensive!A full range of engineering services performed by the company BM Engineering, include: a business plan with energy efficient, profitability and the cost of production calculation, design, construction, commissioning, commissioning and service. In addition, the company supplies equipment of its own production, fulfill the certification and automation of built plants.
The unique biomass (wood chips and sawdust) processing module МБ-3 was designed by using the latest technology, which allows leaving biological materials not dried before pressing with large energy consumption. We wash it in hydraulic washer. Contaminants (metal, soil particles, dust) is removed by water stream. Wet and clean raw material particle by a conveyor and then through a sieve receives into the processing module input hopper. Rotary screw grinds wet biomass and pushes it through a sieve. The biochemical reactions in the wood’s cells (biopolymers) generates heat. The optimum temperature of the hydrated mass thermal stabilization unit supports. Heat pump secure heated water circulation around the all-processing loop. The automation system check whole technological process.
- hydraulic washer;
- biomass processing module;
- heat pump;
- thermal stabilization unit;
- automation process system.
- capacity - 1000 kg / h;
- electric power - up to 100 kW;
- Input raw materials: particle size - up to 4 cm, humidity - up to 50%;
- transport dimensions – 2000*2200*12000 mm;
- weight - 16700 kg.
Only in the first half of 2015 was held 6 specialized seminars "Pellet’s production Basics". About 200 listeners where trained. From the second half of 2015 seminars are held monthly and are increasingly popular with listeners. Those experts, who attended all the lectures and looked at the operating equipment, completely changed the attitude towards technology pellet’s production. Wet pressing method - absolutely new and innovative approach to the biomass processing with the best future.
The full agricultural and wood waste Biorefinery implementation is one of the ways to the the economy prosperity. Energy independence of the Ukraine and the energy-efficient economy construction can be achieved by increasing energy producing from renewable energy sources, biofuel’s certification, energy efficiency. And if in addition instill to public the energy efficient thinking basics, attract targeted investments to green energy sector and eliminate the corruption and incompetence, the energy independence of Ukraine will be provided for ever.
The only in Ukraine course of solid biofuel quality managers and production where organized to educate specialists of the production, sale and export of biofuels enterprises for basics of manufacturing the second and third generation pellet’s technologies (Torrefaction), the quality management system of production and products, the European certification system for pellets.
The company «BM Engineering» designs, manufactures, installs and certifies the most modern pellet and mixed fodder productions. Performs certification of productions and finished products for compliance with ENplus and ISO standards. Our unique and innovative technology are the key to your success.
Seminar “Pellet’s producing efficient"Leading experts in the field of biomass processing, known design engineers under the Vladimir Bunetsky direction spend unique in its content the seminar "Efficient Pellet’s Production"
Learn more about the schedule of seminars and opportunities for participation you can Here.
